The E-Z Crusher Model B is perfect for the local recycling yard looking to crush scrap automobile bodies and ferrous metal. It can also be used for custom crushing operations.

Opening Size

20" x 7'6" x 7'7"

Overall Length

43'5"

Wiry and Capable

The Model B Crusher weighs just 49,000 lbs. but stacks up to its bigger brother’s strength, flexibility and speed. With 8-inch cylinders and a range of available drive motors, the Model B is the ideal solution for many recycling applications.

Efficient Crushing Cycle

The Model B Crusher can reduce scrap automobile bodies and ferrous metal into neat bundles in just 45 seconds. No matter how demanding your recycling operations may be, the Model B Crusher can keep up.

Stable on any Surface

Integrated outriggers provide additional support and stability, making it easy to position the crusher on any surface, in any corner of your recycling yard.

Fully Customizable Operation

Each cylinder can be operated independently of the other, giving you increased leverage and maneuverability during crushing cycles.

Additional Specifications

Hydraulics

System Pressure 2500 psi
Port Reliefs Set At 2650 psi
Cylinders 8" bore
Travel 72"
Shaft 2.5" rod

Opening

Size 20" x 7'6" x 7'7"

Overall

Weight 49,000 lbs
Length 43'5"
Travel & Operating Height 13'3"
John Deere or Volvo Motor option available

Want More Information About Our Model B Crusher?

At E-Z Crusher, we know that the details matter when comparing your crushing equipment options. Our sales team is here to provide the information and advice you need. Contact us to learn more about the Model B Crusher today.

View Our Other Crushers

E-Z Crusher offers a wide selection of machines, allowing you to select the equipment that best fits your specific recycling needs. Compare each of our machines to learn more.

E-Z Crusher Model A

With 10-inch cylinders and a hydraulic system capable of delivering 2500 psi, our Model A Crusher is up to the challenge of even the most rigorous and demanding scrap automobile and metal recycling applications.

E-Z Log Baler Model 4

The larger your recycling operation, the more important and difficult the task of baling loose metals becomes. The E-Z Log Baler Model 4 is up to the challenge of taking on even the largest piles of ferrous scrap with ease and efficiency.
